Schneider TSX3722001 PLC - Modular Base Controller

Core Product Overview

• The Schneider Electric TSX3722001 is a modular base controller.
• This unit delivers reliable automation for industrial applications.
• It belongs to the proven TSX Micro PLC series from Schneider.

Key Technical Specifications

• Brand & Model: Schneider Electric TSX3722001
• Input Voltage: 100-240V AC (90-264V AC range)
• Memory: 20Kwords RAM, expandable to 128Kwords
• Communication: Uni-Telway & Modbus RTU at 19.2 kbit/s
• Output Current: 0.5A with overload protection
• Real-Time Clock: Built-in for time-sensitive operations
• Task Capacity: 1 fast, 1 master, and 16 event tasks

Performance & Durability

• Operating Temperature: 0°C to 60°C range
• Noise Immunity: Withstands microbreaks under 20ms
• EMC Compliance: Meets IEC 1000-4-2 Level 3 standards
• System Overhead: Only 2.3ms for master task
• Secondary Power: Provides 24W total useful power
• Protection: Short-circuit and overload protection included

Installation & Setup

• Mount the TSX3722001 on a standard DIN rail
• Connect power within 90-264V AC range
• Use three expansion slots for I/O modules
• Configure Uni-Telway or Modbus RTU communication
• Insert PCMCIA card for expanded memory if needed

Packaging Details

• One Schneider Electric TSX3722001 controller unit
• Includes mounting brackets and necessary hardware
• Shipping via FedEx, UPS, or DHL carriers
• Net weight: 1.75 kg (3.00 lbs)

Frequently Asked Questions

What is the main function of this controller?

The TSX3722001 serves as the central CPU for TSX Micro PLC systems.

Can I expand the memory capacity?

Yes, use a PCMCIA card to expand to 128Kwords for larger programs.

What communication protocols are supported?

It supports Uni-Telway and Modbus RTU protocols simultaneously.

Is this suitable for harsh environments?

Yes, with wide temperature range and high noise immunity.

How many expansion slots are available?

The controller provides three slots for additional I/O modules.

What power supply do I need?

Any standard 100-240V AC industrial power supply works.

Does it include a real-time clock?

Yes, the TSX3722001 has a built-in real-time clock.

What protection features are included?

It has both overload protection and short-circuit protection.
