Thrust Transmitter | 991-01-XX-01-00 MOD 288865-01

Product Description

The Bently Nevada 991-01-XX-01-00 proximity sensor delivers precise vibration and position measurement for industrial machinery. Compact design (0.43 kg) with BNC connector ensures easy integration. Ideal for monitoring rotating equipment with high reliability.

Key Features

• Wide linear range: 0.25–1.65 mm (10–65 mils)
• High sensitivity: 7.87 mV/μm ±6.5%
• Works with targets ≥9.5 mm diameter
• 3-meter leadwire, optional 5m/7m extensions

Technical Specifications

• Brand: Bently Nevada
• Model: 991-01-XX-01-00 (Full suffix)
• Output: 200 mV/mil, 10 kΩ impedance
• Accuracy: ±6.5% @30mm target
• Operating temperature: -30°C to +100°C

Installation & Compatibility

Mount sensor within 1.2-inch of target surface. Compatible with 10 MΩ load systems. Certified for use with ISO 9001-compliant machinery.

What's Included

• Proximitor sensor with BNC connector
• Calibration certificate
• 1-year limited warranty

Real-World Use

Monitors turbine shaft vibration in power plants. Trusted by oil/gas operators for pump health analysis.
