Lenze Servo Controller | 5.5kW 9300 Series EVS9325-EPV004

High-Performance Servo Control with the Lenze EVS9325-EPV004

The Lenze EVS9325-EPV004 servo controller provides precise position control for demanding automation. This panel-mount unit from the Series 9300 offers robust power in a compact form. It ensures reliable operation for various industrial machinery applications.

Core Technical Specifications

• Model & Type: This is the Lenze EVS9325-EPV004 position servo controller.
• Rated Output: The unit delivers a strong 5.5 kilowatt (7.4 horsepower).
• Voltage Range: It operates on a 400-480V AC 3-phase input supply.
• Output Voltage: The controller provides a variable 0 to 480 Volts AC output.
• Input Frequency: It is compatible with both 50 Hz and 60 Hz power systems.

Environmental & Physical Specifications

• Operating Range: Reliable performance from -10°C to 60°C ambient temperature.
• Storage Range: Safe storage is possible from -25°C to 60°C.
• Enclosure Rating: The unit features an IP20 rating for basic protection.
• Cooling Method: Integrated fan cooling ensures stable thermal performance.
• Unit Weight: The controller weighs approximately 14.46 lbs (6.56 kg).

Installation & Interface Guide

• Mount the servo controller vertically on a standard electrical panel.
• Ensure proper spacing around the unit for optimal airflow and cooling.
• Connect the three-phase power wires to the correctly marked terminals.
• Use the bright LED display to monitor status and fault codes easily.
• Configure the safe standstill function via the integrated digital inputs.

Package Contents & Delivery

• One Lenze EVS9325-EPV004 servo controller unit.
• Complete set of necessary mounting hardware and brackets.
• Detailed installation manual and parameter list for setup.
• We ship all orders using reliable services: FedEx, UPS, or DHL.
• This product includes a standard 12-month warranty for your assurance.

Frequently Asked Questions (FAQ)

• What type of servo motors pair with this controller?
• The EVS9325-EPV004 works optimally with Lenze MCS series servo motors. Always verify the motor's voltage and current ratings match the controller's output.
• Is this drive suitable for a high-vibration environment?
• While robust, for high-vibration areas, ensure the panel mounting is secure. Using vibration-dampening mounts can further enhance longevity.
• How is the position feedback typically handled?
• This position controller receives feedback via a digital encoder interface. You must connect a compatible encoder from the servo motor.
• Can I implement electronic gearing or camming with this unit?
• Yes, advanced functions like electronic gearing are supported. You configure these motion profiles through the controller's software.
• What is the typical resolution for positioning commands?
• The system supports high-resolution positioning. The exact value depends on the connected encoder, often exceeding 1 million counts per revolution.
