2090-CFBM7DF-CEAA60 Motor Feedback Cable Allen-Bradley

Core Product Overview

• The Allen-Bradley 2090-CFBM7DF-CEAA60 is a motor feedback cable.
• This 60-meter cable connects high-resolution encoders to drive systems.
• It is designed for precise motor feedback in industrial automation.

Key Technical Specifications

• Manufacturer & Model: Allen-Bradley 2090-CFBM7DF-CEAA60
• Cable Length: 60 meters long for flexible installation
• Cable Function: Motor Feedback Only connection
• Encoder Type: SIN/COS High-Resolution/Resolver
• Drive End: Flying-lead connection type
• Motor End: SpeedTec DIN Connector
• Flex Type: Standard (Non-Flex) cable construction

Connection & Compatibility Features

• Motor End Connector: SpeedTec DIN standard connector
• Drive End Connection: Flying-lead for flexible termination
• Encoder Compatibility: SIN/COS high-resolution encoders
• Signal Type: Resolver feedback signals
• Cable Construction: Standard non-flexible design
• Applications: Motor drive feedback systems

Physical & Installation Specifications

• Length: 60 meters (approximately 197 feet)
• Connector Type: SpeedTec DIN to flying-lead
• Cable Type: Standard fixed installation cable
• Shielding: Proper shielding for signal integrity
• Durability: Industrial-grade cable construction
• Installation: For fixed, non-flexing applications

Ordering & Configuration Details

• Bulletin Number: 2090 SpeedTEC Series
• Cable Code: CFBM7DF-CEAA60
• Function: Motor feedback only cable
• Length Designation: CEAA60 = 60 meters
• Compatibility: Allen-Bradley drive systems
• Condition: New original equipment

Installation & Application

• Connect SpeedTec DIN end to motor encoder
• Terminate flying-lead end to drive feedback input
• Use for SIN/COS high-resolution encoder signals
• Install in fixed positions (non-flexing applications)
• Ensure proper cable routing for signal protection

Packaging & Delivery

• One Allen-Bradley 2090-CFBM7DF-CEAA60 feedback cable
• Original packaging with length identification
• Shipping via FedEx, UPS, or DHL express service
• 60-meter cable on reel or coiled for protection

Frequently Asked Questions

What type of encoder does this cable support?

The 2090-CFBM7DF-CEAA60 supports SIN/COS high-resolution encoders.

What are the connector types?

SpeedTec DIN connector on motor end, flying-leads on drive end.

Is this a flexible or fixed installation cable?

This is a standard non-flex cable for fixed installations.

What is the cable length?

It is 60 meters (approximately 197 feet) long.

What drive systems is this compatible with?

It is designed for Allen-Bradley SpeedTEC compatible drive systems.
