Bently Nevada 3500/25-02-01-00 | Enhanced Keyphasor

Core Product Overview

• The Bently Nevada 3500/25-02-01-00 is an Enhanced Keyphasor Module.
• This module provides precise timing signals for machinery monitoring.
• It enables accurate measurement of rotational speed and phase reference.

Key Technical Specifications

• Manufacturer & Model: Bently Nevada 3500/25-02-01-00
• Channel Configuration: 02 = Two half-height 2-channel cards (4 total channels)
• I/O Module Type: 01 = Internal Termination Module
• Agency Approval: 00 = Not Required
• Total Channels: 4 independent Keyphasor input channels
• Origin: Manufactured in the United States of America
• Documentation: Certificate of Origin (COO) available

Functional Features

• Signal Conditioning: Processes keyphasor transducer signals
• Timing Reference: Provides rotational timing for vibration analysis
• Internal Terminations: Built-in termination resistors simplify wiring
• Module Format: Two half-height cards in single module housing
• Compatibility: Works with Bently Nevada 3500 monitoring system
• Applications: Turbines, compressors, pumps, and rotating machinery

Physical Specifications

• Shipping Weight: 2 Kg total package weight
• Module Format: Enhanced module with two half-height cards
• Mounting: Standard 3500 series rack installation
• Connections: Internal terminations for transducer inputs
• Construction: Industrial-grade components for reliability
• Design: Compact form factor for efficient space utilization

Ordering & Configuration Details

• Base Model: 3500/25 Enhanced Keyphasor Module
• First Option: 02 = Two 2-channel cards (4 total channels)
• Second Option: 01 = I/O Module with Internal Terminations
• Third Option: 00 = No Agency Approval Required
• Complete Part Number: 3500/25-02-01-00
• Condition: New original equipment from factory

Installation & Configuration

• Install the 3500/25-02-01-00 module in a 3500 system rack
• Connect keyphasor transducers to the four input channels
• Utilize internal terminations - no external resistors required
• Configure channel parameters in the 3500 configuration software
• Verify timing signals with machinery rotation

Packaging & Delivery

• One Bently Nevada 3500/25-02-01-00 Enhanced Keyphasor Module
• Includes two half-height 2-channel keyphasor cards
• Original factory packaging with installation documentation
• Shipping via FedEx, UPS, or DHL express delivery
• Certificate of Origin available upon request

Frequently Asked Questions

How many keyphasor channels does this module provide?

The 3500/25-02-01-00 provides four independent keyphasor channels.

What does "internal terminations" mean?

It has built-in termination resistors, eliminating the need for external resistors.

Is this a single module or multiple cards?

It is one module containing two half-height 2-channel cards.

What is the main function of a keyphasor module?

It provides timing reference signals for vibration analysis of rotating machinery.

Where is this product manufactured?

It is manufactured in the United States of America.
