Bently Nevada 3500/92-04-01-02 | Hazardous Area Gateway

Core Product Overview

• The Bently Nevada 3500/92-04-01-02 is a certified Communication Gateway.
• This module provides robust connectivity for 3500 monitoring systems.
• It features hazardous area certifications for safety-critical applications.

Key Technical Specifications

• Manufacturer & Model: Bently Nevada 3500/92-04-01-02
• I/O Module Type: 04 = Ethernet/RS485 Modbus Interface
• Memory Type: 01 = Low Memory Configuration
• Agency Approval: 02 = CSA, ATEX & IECEx Certified
• Hazardous Area: Approved for use in explosive atmospheres
• Origin: Manufactured in the United States of America
• Documentation: Certificate of Origin (COO) available

Communication & Safety Features

• Protocol Support: Modbus TCP/IP and Modbus RTU protocols
• Interfaces: Ethernet and RS485 communication ports
• Certifications: CSA, ATEX, and IECEx for hazardous locations
• Data Bridging: Connects 3500 system to plant networks
• Safety: Designed for use in explosive atmosphere zones
• Reliability: Industrial-grade components for continuous operation

Physical Specifications

• Main Board: 241 mm x 24.4 mm x 242 mm dimensions
• I/O Modules: 241 mm x 24.4 mm x 99.1 mm dimensions
• Weight: 1.26 Kg total module weight
• Mounting: Standard 3500 series rack installation
• Construction: Robust industrial housing
• Connectors: Industrial Ethernet and RS485 terminals

Ordering & Configuration

• Base Model: 3500/92 Communication Gateway
• First Option: 04 = Ethernet/RS485 Modbus I/O Module
• Second Option: 01 = Low Memory Type
• Third Option: 02 = CSA/ATEX/IECEx Agency Approval
• Complete PN: 3500/92-04-01-02
• Availability: New original stock ready for shipment

Installation & Integration

• Install the 3500/92-04-01-02 in a 3500 monitoring system rack
• Connect Ethernet cable for Modbus TCP/IP network communication
• Wire RS485 connections for Modbus RTU serial communication
• Configure for hazardous area operation per certification requirements
• Map vibration and process data to Modbus registers

Packaging & Delivery

• One Bently Nevada 3500/92-04-01-02 Communication Gateway
• Original factory packaging with all safety documentation
• Shipping via FedEx, UPS, or DHL express international service
• Certificate of Origin (COO) available upon request

Frequently Asked Questions

What communication interfaces does this gateway have?

The 3500/92-04-01-02 provides both Ethernet and RS485 Modbus interfaces.

What safety certifications does it hold?

It is certified for hazardous areas with CSA, ATEX, and IECEx approvals.

Where is this product manufactured?

This gateway is manufactured in the United States of America.

What is the "04" in the model number?

This indicates it has the Ethernet/RS485 Modbus I/O module type.

Is documentation available for customs?

Yes, a Certificate of Origin (COO) is available upon request.
