GE 369B1859G0018 eBUS Interface Board

Introducing the GE Nexus 369B1859G0018 eBUS Interface Board

The 369B1859G0018 eBUS interface board provides robust industrial communication for GE Nexus systems. This board combines both PNP and NPN transistor outputs in one symmetrical design. It enables flexible connectivity across various transmission media with excellent noise immunity characteristics.

Core Technical Specifications & Design

• Brand & Model: GE Nexus 369B1859G0018
• Interface Type: eBUS Industrial Fieldbus Board
• Output Configuration: Combined PNP and NPN transistor outputs
• Signal Symmetry: Symmetrical positive/negative output signals
• Connection Flexibility: Compatible with both single-ended and differential receivers
• Noise Immunity: Enhanced electromagnetic interference resistance
• Transmission Distance: Maximum 100 meters effective range

Communication & Transmission Specifications

• Primary Medium: Twisted pair cable for differential signal transmission
• Alternative Media: Supports:
  • All standard electrical conductors
  • Fiber optic cables for electrical isolation
  • Radio frequency wireless transmission
• Reception Modes:
  • Differential reception for high noise environments
  • Single-ended reception for simpler installations
• Bus Architecture: Optimized for industrial fieldbus networks

Electrical & Performance Characteristics

• Output Current Capacity: Suitable for standard industrial signal levels
• Signal Integrity: Maintains data integrity over maximum distance
• Voltage Compatibility: Designed for industrial control voltage ranges
• Response Time: Optimized for real-time industrial communication
• Data Rate: Supports standard fieldbus communication speeds

Mechanical & Environmental Specifications

• Board Construction: Industrial-grade PCB with robust components
• Connection Interfaces: Standard industrial terminal connections
• Mounting: Compatible with Nexus system backplanes
• Operating Temperature: Standard industrial temperature range
• Environmental Protection: Suitable for controlled industrial environments

Packaging & Shipping Information

• Package Includes: One (1) 369B1859G0018 eBUS interface board
• Shipping Methods: International shipping via FedEx, UPS, and DHL
• Standard Packaging: ESD-protective packaging for sensitive electronics

Installation & Configuration Guide

• Install this eBUS board in the appropriate Nexus system slot
• Select PNP or NPN output mode based on your connected devices
• Choose transmission medium (twisted pair, fiber, or wireless) per application needs
• Configure for differential reception in electrically noisy environments
• Utilize single-ended reception for simpler, shorter-distance connections
• Verify signal integrity across the installed transmission distance

Frequently Asked Questions (FAQ)

What are PNP and NPN outputs?

PNP (sourcing) and NPN (sinking) are two transistor output types. The 369B1859G0018 combines both for compatibility with different sensor and actuator technologies.

What is the advantage of symmetrical output signals?

Symmetrical positive/negative outputs provide better noise rejection and signal integrity, especially important for differential communication over longer distances.

When should I use differential vs single-ended reception?

Use differential reception in electrically noisy environments or for longer cable runs. Single-ended reception is sufficient for shorter distances in cleaner electrical environments.

What applications benefit from this flexible design?

This board is ideal for mixed industrial environments where equipment from different manufacturers (with different I/O types) must connect to the same control system.

Can I use different transmission media simultaneously?

While the board supports multiple media types, typically one primary medium is selected per installation based on distance, noise, and isolation requirements.
