Introducing the Schneider Electric PC-E984-275 CPU Module

The PC-E984-275 is a high-performance processor for Modicon automation systems. This CPU module delivers fast processing for complex industrial applications. It operates on 24V DC power and offers substantial memory for advanced control tasks.

Core Technical Specifications & Performance

• Brand & Model: Schneider Electric PC-E984-275
• Power Supply: Operates on 24V DC at 1 Amp current
• Processor Memory: Large 512 KB memory capacity
• Data Registers: Provides 1920 registers for data handling
• Scan Speed: Fast 2.5 ms/k scan time for rapid execution
• Communication Ports: Two Modbus ports plus one Modbus+ port
• Local I/O Capacity: Manages 256 local input/output points
• Total System I/O: Controls up to 512 inputs and 512 outputs

System Architecture & Expansion

• I/O Drops: Supports 1 local I/O drop connection
• Rack Expansion: Expands to 4 racks for larger system configurations
• Physical Weight: Robust construction at 3.00 lbs (1.36 kg)
• Controller Class: Advanced CPU module for Modicon 984 series PLCs

Packaging & Shipping Information

• Package Includes: One (1) PC-E984-275 CPU module unit
• Shipping Methods: Worldwide shipping via FedEx, UPS, and DHL carriers
• Standard Packaging: Industrial-grade packaging ensures component protection

Installation & Integration Guide

• Install this CPU module in your Modicon 984 series PLC rack system
• Provide stable 24V DC power within the 1 Amp specification
• Connect I/O modules to utilize the 256 local point capacity
• Use the dual Modbus ports for flexible network communication
• Expand your control system with up to 4 additional racks as needed
• The fast 2.5 ms/k scan time supports responsive real-time control

Frequently Asked Questions (FAQ)

What is the memory capacity of this CPU module?

The PC-E984-275 features a substantial 512 KB of memory for storing complex control programs and data.

What power supply does this module require?

This CPU module requires a 24V DC power supply and draws approximately 1 Amp of current during operation.

How fast is the processor scan time?

With a scan time of 2.5 milliseconds per kilobyte, this processor offers fast execution for demanding control applications.

What communication options are available?

The module provides two Modbus ports and one Modbus+ port for connecting to HMIs, SCADA systems, and other network devices.

Can this CPU handle large automation systems?

Yes, with support for up to 512 I/O points and expansion to 4 racks, the PC-E984-275 can manage substantial control systems.
