Schneider Electric 140CPU65260C | Process Control CPU

Core Product Overview

• The Schneider Electric 140CPU65260C is a high-performance Unity processor.
• This 266 MHz CPU is optimized for complex process control applications.
• It supports extensive I/O systems with multiple networking options.

Key Technical Specifications

• Manufacturer & Model: Schneider Electric 140CPU65260C
• Clock Frequency: 266 MHz processing speed
• Local Racks: Supports 2 local rack configurations
• Distributed I/O: 63 stations maximum
• Communication: Built-in Ethernet router capability
• Memory: 3072 kB internal RAM, expandable via PCMCIA
• Bus Current: 2760 mA backplane requirement

Performance & Processing Features

• Instruction Speed: 10.28 Kinst/ms for 100% Boolean operations
• Task Structure: 1 master, 1 fast, 128 I/O interrupt, 128 interrupt tasks
• System Overhead: 0.2 ms fast task, 1 ms master task
• Memory Expansion: PCMCIA card for up to 7168 kB program memory
• Application Focus: Optimized for process control applications
• Processing Power: 10.07 Kinst/ms mixed Boolean/numerical operations

I/O & Network Capabilities

• Local I/O: Unlimited local I/O (26 slots maximum per rack)
• Distributed I/O: 63 Modbus Plus distributed stations
• Remote I/O: 31 S908 remote I/O drops (31744 I/O points)
• Ethernet I/O: 31 Ethernet remote I/O drops
• Special I/O: Counter, high-speed interrupt, accurate time stamping
• Network Support: Modbus Plus, Ethernet TCP/IP, Profibus DP, AS-Interface

Communication & Integration

• Integrated Ports: 1 Modbus Plus, 1 Ethernet TCP/IP, 1 Modbus, 1 USB
• Ethernet Router: Built-in routing capability
• Optional Modules: 6 expansion slots for communication modules
• Protocol Support: Modbus, Modbus Plus, Ethernet TCP/IP, Profibus DP
• Maximum Connections: 6 Ethernet TCP/IP, 6 Modbus Plus, 6 Profibus DP
• Serial Communication: Modbus RS232/485 ASCII support

Physical & Environmental Specifications

• Dimensions: 18.5 cm W x 11 cm D x 33 cm H
• Weight: 1.432 kg total weight
• Protective Coating: Conformal coating Humiseal 1A33
• Temperature: Industrial operating temperature range
• Hazardous Locations: ATEX Zone 2, IEC-Ex certified
• Certifications: CSA, CE, GOST, UL, Marine approvals

Ordering & Application Details

• Product Line: Modicon Quantum Automation Platform
• Part Number: 140CPU65260C
• Processor Type: Unity Processor for process control
• Safety Standards: HazLoc compliant for hazardous areas
• Origin: Manufactured in France
• Applications: Complex process control, batch processing, SCADA

Installation & Programming

• Install the 140CPU65260C in Quantum main rack
• Connect up to 2 local racks for I/O expansion
• Configure distributed I/O network with up to 63 stations
• Program using Unity Pro software with advanced process control
• Utilize built-in Ethernet router for network segmentation

Packaging & Delivery

• One Schneider Electric 140CPU65260C Unity processor
• Includes all communication cables and documentation
• Shipping via FedEx, UPS, or DHL express international
• Original factory packaging with conformal coating
