Schneider Electric 140DDM69000 | 8-Point I/O Module

Core Product Overview

• The Schneider Electric 140DDM69000 is a mixed I/O module.
• This module provides both digital inputs and outputs in single unit.
• It offers flexible configuration for various industrial control applications.

Key Technical Specifications

• Manufacturer & Model: Schneider Electric 140DDM69000
• Total I/O Points: 8 digital channels total
• Input Channels: 4 discrete inputs (sink logic)
• Output Channels: 4 discrete outputs (sink/source selectable)
• Voltage Range: 19.2 to 156.2 VDC wide range
• Output Technology: Solid State with isolation
• Bus Current: 350 mA backplane requirement

Electrical Specifications

• Input Logic: Sinking input configuration
• Output Logic: Configurable sink or source operation
• Leakage Current: Maximum 1.2 mA at 150 VDC
• Isolation: Output channels are isolated
• Solid State: No mechanical contacts for longer life
• Response Time: Fast solid-state switching

Physical & Environmental Specifications

• Module Weight: 1.50 lbs (0.68 kg)
• Dimensions: 163 mm H x 45 mm W x 312 mm D
• Mounting: Standard Quantum rack installation
• Construction: Industrial-grade components
• Format: Mixed I/O module design
• Compatibility: Modicon Quantum series racks

Installation & Configuration

• Wiring Flexibility: Outputs configurable as sink or source
• Voltage Range: Wide 19.2-156.2 VDC operation
• Application: Ideal for machine control and sequencing
• Diagnostics: Status indicators for each channel
• Maintenance: Solid-state design for reduced maintenance
• Integration: Seamless Quantum system integration

Ordering & Application Details

• Product Line: Modicon Quantum Automation Platform
• Part Number: 140DDM69000
• Module Type: Mixed Digital I/O Module
• I/O Configuration: 4 inputs + 4 outputs balanced design
• Technology: Solid-state outputs for reliability
• Typical Use: Machine control, process sequencing, equipment monitoring

System Integration

• Install the 140DDM69000 in Quantum rack system
• Configure 4 inputs as sinking logic for sensor connection
• Set 4 outputs as either sinking or sourcing based on load requirements
• Connect devices within 19.2-156.2 VDC voltage range
• Verify isolation and proper operation of all channels

Packaging & Delivery

• One Schneider Electric 140DDM69000 mixed I/O module
• Includes installation guide and wiring diagrams
• Shipping via FedEx, UPS, or DHL express delivery
• Original factory packaging with documentation

Frequently Asked Questions

How many I/O points does this module have?

The 140DDM69000 has 8 total points: 4 inputs and 4 outputs.

What voltage range does it support?

It supports a wide 19.2 to 156.2 VDC operating range.

Can outputs be configured differently?

Yes, outputs are individually configurable as either sinking or sourcing.

What type of outputs does it use?

It uses solid-state isolated outputs for reliability and long life.

What is the bus current requirement?

It requires 350 mA from the Quantum backplane.
