Schneider Electric 140NOE21110C Ethernet Module

The Schneider Electric 140NOE21110C is a single-channel Ethernet TCP/IP module for the Modicon Quantum platform. It provides reliable network connectivity for industrial automation. This module enables seamless data exchange over standard Ethernet networks.

Core Product Specifications

• Brand & Model: Schneider Electric 140NOE21110C
• Product Type: Single-Channel Ethernet TCP/IP Module
• Network Protocol: Standard Ethernet TCP/IP for industrial communication.
• Primary Applications: Material handling, packaging systems, textile machinery.
• Compatibility: Designed for integration with Modicon Quantum PLC systems.

Environmental & Operating Ratings

• Operating Temperature: 0°C to 40°C (32°F to 104°F).
• Storage Temperature: 0°C to 50°C (32°F to 122°F).
• Humidity Rating: Up to 80% relative humidity, non-condensing.
• Maximum Altitude: 1000 meters for both operation and storage.
• Operating Environment: Clean, indoor settings without corrosive chemicals.

Application & System Integration

• Connects Modicon Quantum controllers to plant-wide Ethernet networks.
• Enables remote monitoring, data collection, and supervisory control.
• Facilitates integration with HMI/SCADA systems and other networked devices.
• Ideal for creating connected systems in modern industrial automation.

Frequently Asked Questions (FAQ)

What is the main purpose of the 140NOE21110C module?

This module adds a standard Ethernet TCP/IP port to a Modicon Quantum rack. It allows the PLC to communicate over Ethernet for control and data exchange.

What does "single-channel" mean for this Ethernet module?

It provides one physical Ethernet network connection (port). You connect one Ethernet cable from your plant network directly to this module.

Is this module suitable for connecting to the internet?

It can connect to local networks that may have internet access. However, direct internet exposure requires proper firewalls and network security configuration for safety.

What software is used to configure this TCP/IP module?

You configure it using Schneider Electric's Unity Pro programming software. This software sets the IP address and network parameters for the 140NOE21110C.

Can I use this module in a panel located outdoors?

No, it is rated for clean indoor environments only. It is not designed for outdoor use, wet conditions, or areas with corrosive fumes.

What types of industrial applications is it best suited for?

It is ideal for material handling, packaging lines, and textile machines that require reliable Ethernet communication for control and monitoring.

How do I assign an IP address to this module?

The IP address is assigned through the configuration in the Unity Pro project. You can set a static IP or configure it for DHCP, depending on your network setup.
