Schneider Electric 140NOL91100 | 1.25 Mbps Network Module

Core Product Overview

• The Schneider Electric 140NOL91100 is a LON network transceiver.
• This module enables Local Operating Network connectivity for Quantum systems.
• It provides reliable communication using LonWorks FTT-10 protocol.

Key Technical Specifications

• Manufacturer & Model: Schneider Electric 140NOL91100
• Interface Type: LON (Local Operating Network)
• Data Rate: 1.25 Mbps maximum transfer speed
• Network Protocol: LonWorks FTT-10 standard
• Power Supply: 24 VDC operating voltage
• Operating Temperature: 0°C to 60°C
• Compliance: CE, UL, cUL certified

Network & Communication Features

• Protocol Support: LonWorks FTT-10 network protocol
• Data Transfer: 1.25 megabits per second capability
• Network Integration: Connects Quantum PLCs to LON networks
• Topology Support: Free topology network configuration
• Distance: Up to 500 meters network segment length
• Node Capacity: Supports multiple nodes on network

Physical & Environmental Specifications

• Module Weight: 0.06 lbs (0.03 kg) lightweight design
• Mounting: Direct Modicon Quantum rack installation
• Connector Type: Screw terminal for secure connections
• Humidity Range: 10% to 95% RH non-condensing
• Construction: Industrial-grade components
• Dimensions: Compact Quantum module size

Installation & Configuration

• Rack Mounting: Installs in standard Quantum rack
• Power Connection: 24 VDC power supply required
• Network Wiring: Screw terminal connections for LON bus
• Configuration: Requires LonWorks network configuration tools
• Integration: Connects Quantum processors to LON devices
• Diagnostics: Status indicators for network activity

Ordering & Application Details

• Product Line: Modicon Quantum Automation Platform
• Part Number: 140NOL91100
• Module Type: LON Network Transceiver
• Network Standard: LonWorks FTT-10 compliant
• Typical Applications: Building automation, industrial control networks
• Compatibility: Quantum processors and LON compatible devices

System Integration

• Install the 140NOL91100 in Quantum rack system
• Connect 24 VDC power to module terminals
• Wire LON network using screw terminal connections
• Configure network parameters using LonWorks tools
• Integrate with building management or control systems

Packaging & Delivery

• One Schneider Electric 140NOL91100 LON transceiver module
• Includes installation guide and network documentation
• Shipping via FedEx, UPS, or DHL express delivery
• Original factory packaging with certifications

Frequently Asked Questions

What is the data transfer rate of this transceiver?

The 140NOL91100 supports 1.25 Mbps data transfer on LON networks.

What protocol does it use?

It uses the LonWorks FTT-10 network protocol for communication.

What power supply does it require?

It operates on 24 VDC power from the Quantum system.

What are typical applications for this module?

Building automation, HVAC control, lighting systems, and industrial networks.

What certifications does it have?

It is certified to CE, UL, and cUL standards for safety and compliance.
