Schneider Electric Momentum 170AAI03000 16-Bit AI Base

Introducing the Schneider Electric 170AAI03000 Analog Input Base

The 170AAI03000 is a precision analog input module for Modicon Momentum. It handles eight differential channels for accurate industrial measurements. This base delivers reliable data acquisition in demanding automation environments.

Core Technical Specifications & Performance

• Brand & Model: Schneider Electric 170AAI03000
• Input Channels: 8 differential channels for versatile signal connection.
• Data Resolution: High-precision full 16-bit signed data format.
• Conversion Speed: Fast 12 ms conversion time for rapid signal updates.
• Channel Isolation: 200V DC isolation between channels enhances safety and accuracy.
• System Isolation: 500V AC isolation from channels to ground and bus.
• Wiring Protection: Features internal reverse polarity protection against installation errors.

Robust Design & Operating Environment

• Operating Temperature: Reliable performance from 0°C to 60°C.
• Storage Temperature: Withstands -40°C to 85°C when not in use.
• Humidity Tolerance: Operates at up to 95% relative humidity without condensation.
• Physical Dimensions: Compact size: 5.6" W x 4.9" H x 1.9" D (141.5 x 125 x 47.5 mm).
• Module Weight: Lightweight design at just 0.474 lb (0.215 kg).

Packaging & Shipping Information

• Package Includes: One (1) 170AAI03000 analog input base unit.
• Package Dimensions: 10.236" L x 7.087" W x 2.165" H (26 x 18 x 5.5 cm).
• Shipping Weight: Approximately 14.1 oz (400 grams).
• Shipping Methods: We ship globally via FedEx, UPS, and DHL for reliable delivery.

Installation & Integration Guide

• Mount this base module directly onto your Modicon Momentum DIN rail assembly.
• Connect your differential analog signals to the eight available input channels.
• The module's isolation protects against ground loops and electrical noise interference.
• Internal reverse polarity protection safeguards the module during wiring.
• Ensure your operating environment stays within the specified temperature and humidity ranges.

Frequently Asked Questions (FAQ)

What type of signals does the 170AAI03000 accept?

This module accepts differential analog input signals across all eight channels for precise measurement.

What is the advantage of 16-bit resolution?

The 16-bit signed data format provides high resolution and accuracy for your analog measurements. This gives you fine detail in your process data.

How does the channel isolation benefit my system?

Isolation prevents signal interference between channels and protects the main bus. This ensures measurement accuracy and system safety in noisy industrial environments.

Is the 170AAI03000 suitable for harsh environments?

With its wide temperature range and high humidity tolerance, it performs well in standard industrial settings. It is not designed for washdown or outdoor exposure.

What should I consider when choosing an analog input module?

For high-precision requirements with differential signals, the 170AAI03000 is an excellent choice. Its 16-bit resolution and isolation make it ideal for critical measurements.
