Schneider Electric Momentum 170AAI52040 16-Bit AI Module

Introducing the Schneider Electric 170AAI52040 Analog Input Base

The 170AAI52040 is a precision four-channel input module for Modicon Momentum. It provides reliable differential analog signal acquisition for industrial systems. This base delivers accurate measurements in demanding automation environments with strong electrical isolation.

Core Technical Specifications & Performance

• Brand & Model: Schneider Electric 170AAI52040
• Input Channels: 4 differential analog channels for flexible signal connection
• Data Resolution: High-accuracy full 16-bit signed data format
• Update Rate: 500 millisecond update time for process data
• Channel Isolation: Strong 400V DC isolation between channels for safety
• System Isolation: 500V AC isolation from channels to ground and system bus
• Wiring Protection: Built-in internal reverse polarity protection against installation errors

Robust Design & Operating Environment

• Operating Temperature: Stable performance from 0°C to 60°C
• Storage Temperature: Withstands -40°C to 85°C when not in use
• Humidity Tolerance: Operates at up to 95% relative humidity without condensation
• Physical Dimensions: Compact 5.6" W x 4.9" H x 1.9" D (141.5 x 125 x 47.5 mm)
• Module Weight: Lightweight design at 0.474 lb (0.215 kg)

Packaging & Shipping Information

• Package Includes: One (1) 170AAI52040 analog input base unit
• Shipping Methods: Global shipping via FedEx, UPS, and DHL

Installation & Integration Guide

• Mount this base module directly onto your Modicon Momentum DIN rail
• Connect differential analog signals to the four available input channels
• The high channel isolation protects against ground loops and electrical noise
• Internal reverse polarity protection safeguards the module during wiring
• Ensure operating environment stays within specified temperature ranges
• This module is ideal for slower process applications requiring high accuracy

Frequently Asked Questions (FAQ)

What is the update time of the 170AAI52040 module?

This module updates its analog input values every 500 milliseconds. This suits applications where fast response is not critical but accuracy is important.

Why choose differential analog inputs?

Differential inputs provide superior noise rejection in industrial environments. They ensure more accurate measurements than single-ended inputs, especially over longer cable runs.

What does 400V DC channel isolation provide?

The isolation prevents signal interference between measurement channels. It also protects the module from voltage spikes that could damage sensitive electronics.

Is this module suitable for high-speed control applications?

With its 500ms update time, the 170AAI52040 is best for slower process monitoring. Consider faster modules for motion control or rapid closed-loop applications.

How does this module compare to the 170AAI03000?

The 170AAI52040 has 4 channels with 500ms update, while the 170AAI03000 offers 8 channels with 12ms update. Choose based on your channel count and speed requirements.
