Schneider Electric TSXP571634 Unity Processor | Modicon

The Schneider Electric TSXP571634 is a powerful Unity Processor within the Modicon platform. Designed for demanding automation tasks, it balances substantial I/O capacity with robust processing capabilities in a compact form factor.

Core Product Specifications

• Brand & Model: Schneider Electric TSXP571634
• Product Type: Unity Processor for Modicon Systems
• I/O Capacity: 512 discrete I/O and 24 analog I/O points.
• Application Channels: 8 dedicated channels for specialized functions.
• Power Supply: 5V DC input voltage.
• Current Consumption: 1650 mA.

Memory & Storage

• Memory with PCMCIA Card: 224 kB program memory, 96 kB data memory.
• Memory without PCMCIA Card: 96 kB shared for program and data.
• Expandable storage via PCMCIA card slot for program backup and transfer.

Physical & Environmental Ratings

• Weight: 0.74 kg (1.63 lbs).
• Protection Class: IP20 for installation in protected enclosures.
• Operating Temperature: 0°C to 60°C (32°F to 140°F).
• Storage Temperature: -25°C to 70°C (-13°F to 158°F).
• Operating Altitude: Up to 2000 meters.

Key Features & Applications

• Provides centralized control for medium-complexity machines and processes.
• The 8 application-specific channels support high-speed counting or positioning tasks.
• Suitable for industries such as packaging, material handling, and specialized machinery.
• Offers a scalable solution within the Modicon TSX Premium platform.

Frequently Asked Questions (FAQ)

What is the primary role of this processor?

The TSXP571634 acts as the central brain of a control system, executing logic, processing I/O signals from sensors and actuators, and managing data for automation applications.

What does "512 discrete I/O capacity" mean?

It can manage communication with up to 512 individual on/off devices (like sensors and relays) distributed across connected I/O modules in the rack.

How important is the PCMCIA card?

The PCMCIA card significantly increases available program memory. It is essential for larger, more complex applications and for easily transferring projects between processors.

What are the "application-specific channels" used for?

These are dedicated high-speed inputs/outputs. They are typically used for specialized functions like fast counting, frequency measurement, or pulse train output for controlling stepper/servo drives.

What type of rack or power supply is needed?

This processor must be installed in a compatible Modicon TSX Premium rack, which provides the required 5V DC power. An appropriately sized rack power supply is crucial to deliver the 1650 mA current.
