Schneider Electric TSXP57203M PLC | Modicon Premium Processor

Product Overview: Schneider Electric TSXP57203M PLC

The Schneider Electric TSXP57203M is a powerful Micro PLC from the trusted Modicon Premium series. It offers advanced processing speeds and robust connectivity for demanding automation applications. This unit provides a reliable control solution for a wide range of industrial systems.

Core Technical Specifications

• Brand & Model: Schneider Electric TSXP57203M
• Processing Speed: Executes Boolean instructions in just 0.19 µs without a PCMCIA card.
• System Overhead: Features a 0.3 ms fast task and a 1 ms master task for responsive operation.
• Memory Capacity: Offers 224 KB program storage and 96 KB data RAM with a PCMCIA card installed.
• Communication Ports: Integrated Ethernet TCP/IP (RJ45) and a serial RS485 link for easy networking.
• I/O Capacity: Can manage up to 512 discrete I/O points and 24 analog I/O channels.
• Task Structure: Supports 1 master task, 1 fast task, and up to 32 event-driven tasks.

Performance & Execution Details

• Achieves up to 3.71 thousand instructions per millisecond for maximum efficiency.
• The optional PCMCIA card adds 256 KB of additional data storage for larger projects.
• Instruction execution time slightly varies based on the use of the memory card.
• This TSXP57203M ensures precise and timely control logic execution.

Physical & Environmental Design

• Module Format: Standard form factor for easy integration into control panels.
• Weight: Lightweight design at approximately 1.00 lb (0.45 kg).
• Operating Temperature: Reliable performance from 32°F to 140°F (0°C to 60°C).
• Protection Rating: Front panel is rated IP20 for basic dust and contact protection.
• Standards & Certifications: Complies with UL, IEC, and marine standards for safety.

Installation & System Integration

• Supports configuration with up to 2 communication modules for network expansion.
• Compatible with a system of up to 2 racks (12 slots each) for I/O module expansion.
• Designed for use with Schneider's PL7 Junior/Pro programming software.
• Clear LED indicators (RUN, I/O, ERR, TER) provide immediate status diagnostics.

Packaging & Shipping

• Each TSXP57203M processor ships as one individual unit (PCE).
• Package Dimensions: 10.2" L x 7.09" W x 3.7" H (26 x 18 x 9.5 cm).
• Shipment includes the PLC processor unit ready for installation.
• We ship globally via reliable carriers including FedEx, UPS, and DHL.

Frequently Asked Questions (FAQ)

What is the main advantage of the TSXP57203M processor?

Its key advantage is high-speed execution, with a 0.19 µs Boolean instruction time, making it ideal for fast automation processes.

Does this PLC have built-in Ethernet connectivity?

Yes, it features an integrated Ethernet TCP/IP port (RJ45) for easy connection to plant networks and SCADA systems.

How does the PCMCIA card affect performance?

The card significantly expands data storage but may add a small overhead, changing Boolean execution to 0.25 µs.

What is the difference between the master and fast task?

The fast task (0.3 ms) handles time-critical operations, while the master task (1 ms) manages the main control program.

How do I choose between this and other TSX Micro models?

Choose the TSXP57203M for applications requiring high I/O count (512), analog control, and Ethernet. For smaller projects, consider a base model.

Can I use this for machine safety applications?

While robust, it is a standard control PLC. Always use certified safety modules and relays for critical safety functions.
