Schneider Electric TSXP573623AM | Multi-Rack PLC Processor

Core Product Overview

• The Schneider Electric TSXP573623AM is an advanced micro PLC.
• This controller delivers high-performance automation for complex systems.
• It features integrated Ethernet and serial communication capabilities.

Key Technical Specifications

• Brand & Model: Schneider Electric TSXP573623AM
• I/O Capacity: 1024 discrete I/O and 128 analog I/O points
• Communication: Ethernet TCP/IP (10/100 Mbit/s) + 2 serial links
• Processing Speed: 0.12 µs Boolean instruction execution time
• Rack Support: Manages up to 16 racks for large systems
• Memory: 64 Kwords internal RAM, expandable via PCMCIA
• Task Structure: 1 master, 1 fast, and 64 event tasks

Performance & Communication Features

• Instruction Speed: 6.57K instructions/ms without PCMCIA card
• PCMCIA Slots: 2 slots for memory and communication expansion
• Fieldbus Support: 2 fieldbus modules (1 with CANopen)
• AS-Interface: Up to 8 AS-Interface bus modules
• Process Control: 15 channels managing 45 simple loops
• Serial Ports: Two RS485 ports at 19.2/115 kbit/s

Memory & System Architecture

• Program Memory: Expandable to 384 Kwords with PCMCIA card
• Data Memory: 80 Kwords with memory card installed
• Object Areas: 16384 internal bits and 32K constant words
• Display: LED status indicators on front panel
• Reset Function: Dedicated button for system cold start
• Expansion: Supports extensive I/O and communication modules

Environmental & Operational Ratings

• Operating Temperature: 0°C to 60°C standard industrial range
• Certifications: Complies with major industrial standards
• Mounting: Standard PLC rack installation
• Weight: Lightweight at 1.00 lb (0.45 kg)
• Dimensions: Compact design for space-efficient installation
• Reliability: Designed for continuous industrial operation

Installation & Configuration

• Install the TSXP573623AM processor in your main rack
• Connect Ethernet cable for network communication
• Wire serial devices to the two RS485 communication ports
• Insert PCMCIA cards for memory or communication expansion
• Configure up to 16 racks with I/O and specialty modules

Packaging & Delivery

• One Schneider Electric TSXP573623AM micro PLC processor
• Includes complete installation and programming documentation
• Shipping via FedEx, UPS, or DHL express international service
• Ready for integration into your automation system

Frequently Asked Questions

What is the maximum I/O capacity?

The TSXP573623AM handles 1024 discrete and 128 analog I/O points.

How many communication ports does it have?

It features one Ethernet port and two serial communication ports.

Can it control multiple racks?

Yes, it supports configuration with up to 16 separate racks.

What expansion options are available?

Two PCMCIA slots for memory and communication module expansion.

How many tasks can it manage?

It supports 1 master task, 1 fast task, and 64 event tasks.
