Schneider Electric TSXP575634M TSX Micro PLC Controller

Introducing the Schneider Electric TSXP575634M Micro PLC Processor

The TSXP575634M is a versatile processor for the TSX Micro PLC series. This controller provides reliable performance for various automation applications. It offers expandable memory and balanced I/O capacity for mid-range control systems.

Core Technical Specifications & Performance

• Brand & Model: Schneider Electric TSXP575634M
• Discrete I/O Capacity: 512 I/O points
• Analog I/O Capacity: 24 I/O channels
• Processing Speed: 0.5 µs Boolean execution (0.6 µs with PCMCIA)
• Instructions per ms: 1.05 Kinst/ms (65% Boolean + 35% fixed arithmetic without PCMCIA)
• Internal RAM: 32 Kwords for program and data (base configuration)
• Module Weight: 1.34 lb (0.61 kg) net weight

Memory Expansion & Storage

• Base Memory: 32 Kwords internal RAM for combined program and data
• PCMCIA Expansion: Supports memory expansion cards for additional capacity
• PCMCIA Data Storage: Adds 128 Kwords of additional data storage
• PCMCIA Program Memory: Provides 64 Kwords of extra program space
• Memory with PCMCIA: 32 Kwords data in internal RAM configuration
• Storage Flexibility: Scalable memory solution for growing application needs

Communication & Connectivity

• Integrated Interface: Non-isolated serial link (2x mini DIN, 19.2 kbit/s)
• Network Modules: Supports 1 network module
• Fieldbus Support:
  • 2 AS-Interface bus modules
  • 1 CANopen interface
• Communication Capacity: Balanced connectivity for distributed systems
• Platform: Part of Modicon Premium Automation platform

System Configuration & Expansion

• Rack Configurations:
  • 2 racks of 12 slots each
  • 4 racks with 4/6/8 slots configurations
• Slot Capacity: Up to 64 slots in maximum configuration
• Software: Programmable with Unity Pro software
• Concept: Transparent Ready architecture for connectivity
• Current Consumption: 440 mA at 5V DC (1680 mA in full configuration)
• Module Format: Standard format for TSX Micro systems

Status Indication & Monitoring

• Status LEDs: Four indicators for:
  • Processor running (RUN) - Green
  • I/O module or configuration fault (I/O) - Red
  • Processor or system fault (ERR) - Red
  • Terminal port activity (TER) - Yellow
• Extended Indicators: Additional LEDs in full configuration for Ethernet, collisions, link diagnostics, and RX/TX activity
• Inrush Current: Handles 38 A at 240V / 100V during startup

Environmental & Safety Specifications

• Operating Temperature: 0°C to 60°C (32-140°F)
• Storage Temperature: -25°C to 70°C (-13 to 158°F)
• Humidity Range: 10-95% non-condensing operation
• Altitude Rating: Up to 2000 meters (6561 feet)
• Protection Rating: IP20 enclosure
• Certifications: UL 508, IEC 61131-2, CSA, CE, marine classifications (ABS, DNV, GL, BV, LR, RINA)

Packaging & Shipping Information

• Package Includes: One (1) TSXP575634M PLC processor unit
• Shipping Methods: International shipping via FedEx, UPS, and DHL
• Country of Origin: Manufactured in France
• Return Policy: Returnable product under applicable terms

Installation & Configuration Guide

• Install this processor in your TSX Micro PLC rack system
• Connect serial communication via the two mini DIN ports
• Add PCMCIA memory card if additional program or data storage is needed
• Configure I/O modules within the 512 discrete and 24 analog capacity
• Monitor system status through the four primary LED indicators
• Utilize Unity Pro software for programming and configuration

Frequently Asked Questions (FAQ)

What is the advantage of PCMCIA memory expansion?

The PCMCIA slot allows upgrading from 32Kwords to 192Kwords total memory (128K data + 64K program), providing flexibility for growing applications without replacing the processor.

How many I/O modules can be connected?

With 512 discrete and 24 analog I/O capacity, this processor can handle multiple I/O modules across up to 4 expansion racks.

What communication protocols are supported?

The controller supports serial communication and can interface with AS-Interface and CANopen fieldbus networks through additional communication modules.

Is this processor suitable for process control applications?

With 24 analog I/O channels and expandable memory, the TSXP575634M is well-suited for basic to medium-complexity process control applications.

What is the difference between this and the TSXP572634M model?

The TSXP575634M offers 512 discrete I/O and 24 analog I/O, while the TSXP572634M provides 1024 discrete I/O and 80 analog I/O for larger systems.
