Schneider Modicon Quantum ABFM08S201 Cable Connector

Product Overview

The ABFM08S201 is a cabled connector manufactured by Schneider Electric for the Modicon Quantum automation platform. This 8-channel analog input connector provides reliable signal connectivity with a 2-meter cable for flexible installation in industrial control systems.

Technical Specifications

• Manufacturer: Schneider Electric
• Part Number: ABFM08S201
• Product Type: Cabled Connector for Analog Input
• Product Line: Modicon Quantum Automation Platform
• EAN Code: 3389110945607
• Channels: 8 Analog Input Channels
• Cable Length: 2 meters (6.6 feet)
• Signal Type: Analog Input Signal Transmission
• Connector Type: SUB-D 25-Way Connector
• Wire Gauge: AWG 24 Standard
• Wire Section: 0.22 mm² (0.0003 in²)
• Current Rating: 1 Ampere Maximum
• Voltage Rating: 250 Volts Maximum
• Operating Temperature: -20°C to +60°C (-4°F to 140°F)
• Net Weight: 0.6 kg (1.3 lb)

Connection Specifications

• Connector Style: SUB-D Standard Industrial Connector
• Number of Ways: 25-Pin Configuration
• Electrical Connection: Single Connector Design
• Contact Configuration: 8 Channels for Analog Signals
• Interface Type: Direct PLC Connection
• Mounting: Standard Industrial Mounting

Compatible Products

• Analog Input Module: 140AVI03000 Compatibility
• Analog Counter Module: 140ACI03000 Compatibility
• System Integration: Modicon Quantum PLC Platforms
• Application: Industrial Automation Systems
• Installation: Direct Module Connection

Package Information

• Unit Package (Type 1): Single Unit Configuration
• Units per Package 1: 1 Connector per Box
• Package 1 Dimensions: 22.0 × 21.0 × 5.5 cm (8.7" × 8.3" × 2.2")
• Package 1 Weight: 477.0 g (16.8 oz)
• Bulk Package (Type 2): S02 Configuration
• Units per Package 2: 4 Connectors per Box
• Package 2 Dimensions: 40.0 × 30.0 × 15.0 cm (15.7" × 11.8" × 5.9")
• Package 2 Weight: 2.334 kg (5.146 lb)

Electrical Characteristics

• Signal Integrity: Reliable Analog Signal Transmission
• Current Capacity: 1A per Channel Capability
• Voltage Handling: Up to 250V Operation
• Wire Specifications: AWG 24 with 0.22 mm² Cross-Section
• Connection Reliability: Secure SUB-D Connection
• Performance: Industrial Control Grade

Environmental Specifications

• Temperature Range: Wide -20°C to +60°C Operation
• Industrial Suitability: Harsh Environment Compatible
• Material Quality: PVC Insulation for Durability
• Construction: Robust Industrial Design
• Application Range: Various Industrial Settings

Application Information

• Primary Use: Analog Input Signal Connection
• System Integration: Modicon Quantum PLC Systems
• Industrial Applications: Process Control and Monitoring
• Data Acquisition: 8-Channel Analog Signal Collection
• Control Systems: Automation and Control Applications
• Installation Flexibility: 2-Meter Cable Length Advantage

Key Features

• 8-Channel Analog Input Connection Capability
• 2-Meter Cable Length for Installation Flexibility
• SUB-D 25-Way Industrial Standard Connector
• AWG 24 Wire with 0.22 mm² Cross-Section
• Wide Operating Temperature Range (-20°C to +60°C)
• Compatible with 140AVI03000 and 140ACI03000 Modules
• PVC Insulated Multi-Conductor Ribbon Cable

Installation Benefits

• Easy Connection: Standard SUB-D Connector Interface
• Flexible Routing: 2-Meter Cable for Layout Options
• Reliable Contact: 25-Way Secure Connection
• System Integration: Direct PLC Module Compatibility
• Maintenance: Easy Replacement and Service
• Organization: Ribbon Cable for Neat Installation

Frequently Asked Questions

How many channels does this connector support?
The ABFM08S201 supports 8 analog input channels for comprehensive signal connection in Modicon Quantum systems.

What is the cable length?
This connector features a 2-meter (6.6-foot) cable, providing flexibility for installation in various industrial control panel layouts.

What modules is it compatible with?
It is specifically designed for compatibility with Schneider Electric's 140AVI03000 analog input module and 140ACI03000 analog counter module.

What type of connector does it use?
The connector utilizes a standard SUB-D 25-way industrial connector for reliable and secure signal connections.

What are the electrical specifications?
The connector is rated for 1A current and 250V voltage, with AWG 24 wire (0.22 mm² cross-section) for reliable signal transmission.
