Schneider Momentum 170ENT11001 Ethernet Adapter

Product Overview

The 170ENT11001 is an Ethernet TCP/IP Communication Adapter manufactured by Schneider Electric for the Modicon Momentum automation platform. This industrial Ethernet adapter provides flexible 10/100 Mbit/s connectivity with comprehensive networking features for industrial control systems.

Technical Specifications

• Manufacturer: Schneider Electric
• Part Number: 170ENT11001
• Product Type: Ethernet TCP/IP Communication Adapter
• Product Line: Modicon Momentum Automation Platform
• EAN Code: 3595862034302
• Transmission Rate: 10/100 Mbit/s Auto-Negotiation
• Communication Protocol: Ethernet TCP/IP
• Port Type: 100BASE-TX Ethernet Port
• Connector: RJ-45 Standard Connector
• Access Methods: Master/Slave and Peer-to-Peer (P2P)
• Cable Type: Shielded Twisted Pair Cable
• Maximum Distance: 1,000 m (3,280 ft) Between Devices
• Devices per Segment: 0-32 Devices Maximum
• Operating Temperature: 0°C to 60°C (32°F to 140°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Protection Rating: IP20 Enclosure Protection
• Net Weight: 0.07 kg (0.15 lb)
• Shipping Weight: 0.45 kg (1.00 lb)
• Country of Origin: France (FR)

Network Configuration

• IP Assignment: BOOTP Server for IP Parameter Assignment
• Addressing: Unique IEEE Global MAC Address
• User Control: User-Assigned IP Address Capability
• Topology Support: Multidrop and Star Network Configurations
• Network Design: Flexible System Architecture Support
• Configuration: Easy Setup and Integration

Communication Features

• Speed Flexibility: Auto-Negotiating 10/100 Mbit/s
• Protocol Support: Industrial Ethernet TCP/IP
• Data Integrity: CRC-32 Error Checking Parameter
• Fail State: Fail-Safe Operation Design
• Medium Support: Shielded Twisted Pair Cable
• Industrial Grade: Robust Industrial Communication

LED Status Indicators

• Indicator Configuration: 3 Green LEDs and 1 Yellow LED
• Status Monitoring: Comprehensive Visual Feedback
• Network Status: Clear Connection and Activity Indication
• System Health: Immediate Operational Status Display
• Diagnostic Support: Quick Troubleshooting Assistance

Physical Characteristics

• Protective Treatment: TC Coating Application
• Markings: CE Certification Compliance
• Construction: Industrial-Grade Components
• Design: Standard Momentum Module Format
• Weight: Lightweight at 0.07 kg Net Weight

Package & Shipping

• Category: US1PC3118206
• Discount Schedule: PC31
• Package Type: Single Unit Package
• Units per Package: 1 Adapter per Box
• Package Dimensions: 26.1 × 18.3 × 6.0 cm (10.28" × 7.21" × 2.36")
• Package Weight: 233.0 g (8.22 oz)
• Return Policy: Returnable Item

Network Specifications

• Maximum Distance: 1,000 Meter Cable Length Between Devices
• Segment Capacity: Up to 32 Devices per Network Segment
• Topology Options: Supports Both Star and Multidrop Networks
• Network Architecture: Flexible Industrial Network Design
• Scalability: Expandable System Configuration

Key Features

• 10/100 Mbit/s Auto-Negotiating Ethernet Speed
• Ethernet TCP/IP Protocol with Industrial Reliability
• RJ-45 Connector for Standard Network Cabling
• Master/Slave and Peer-to-Peer Communication Modes
• Four LED Status Indicators for System Monitoring
• IP20 Protection Rating for Industrial Environments
• BOOTP Server Support for Easy IP Configuration

Application Benefits

• Network Flexibility: Supports Multiple Network Topologies
• Easy Integration: Standard Momentum Platform Compatibility
• Reliable Communication: Industrial-Grade Ethernet Performance
• Scalable Design: Supports Up to 32 Devices per Segment
• Robust Construction: Designed for Industrial Environments
• Easy Monitoring: Comprehensive LED Status Indicators

Frequently Asked Questions

What Ethernet speeds are supported?
The 170ENT11001 supports both 10 Mbit/s and 100 Mbit/s Ethernet speeds with auto-negotiation capability.

What communication protocols are used?
This adapter uses Ethernet TCP/IP protocol for reliable industrial network communication with CRC-32 error checking.

What network topologies are supported?
It supports both star network and multi-drop topologies, providing flexibility in system design and installation.

How is IP addressing handled?
The adapter supports BOOTP server for automatic IP assignment and allows user-assigned IP addresses with unique IEEE global addressing.

What is the maximum cable distance?
The maximum cable distance between devices is 1,000 meters (3,280 feet) using shielded twisted pair cable.
