Schneider TSXMFPP128K | Program Backup Memory Card

The Schneider Electric TSXMFPP128K is a Flash EPROM memory extension module for Modicon TSX Premium processors. It adds 128 kB of non-volatile application memory, crucial for storing and backing up complex control programs. This module ensures your automation logic is safely retained, even during a power loss.

Core Product Specifications

• Brand & Model: Schneider Electric TSXMFPP128K
• Product Type: Flash EPROM Memory Extension Module
• Memory Capacity: 128 kB of application memory storage.
• Memory Technology: Reliable Flash EPROM for non-volatile storage.
• Installation Slot: Must be installed in Slot 0 of the compatible processor.
• Compatibility: For TSX57 series processors (TSX570 to TSX574, TSX57C, TSXPCI572/3).

Physical & Environmental Data

• Dimensions (HxWxD): 3.0 cm x 9.5 cm x 5.31 cm.
• Weight: 0.097 lbs (0.044 kg).
• Operating Temperature: -25°C to +70°C.
• Storage Temperature: -40°C to +85°C.
• Shock Resistance: 15 gn for 11 ms.
• Vibration Resistance: 3.5 mm (10-55 Hz).
• Relative Humidity: 5% to 95%, non-condensing.

Compliance & Sustainability

• Environmental: RoHS compliant and classified as a Green Premium product.
• Manufactured to meet high environmental and safety standards.

Packaging Details

• Package Includes: One (1) TSXMFPP128K memory module.
• Package Dimensions: 5.3" L x 3.7" W x 1.2" H.
• Package Weight: 2.8 oz (80 g).

Frequently Asked Questions (FAQ)

What is the purpose of this memory module?

It extends the non-volatile memory of your TSX Premium PLC. This allows you to store larger control programs and retain them safely without battery backup when the controller is powered off.

Which processors is it compatible with?

It is compatible with Modicon TSX Premium processors in the TSX57 series, including models TSX570, TSX571, TSX572, TSX573, TSX574, TSX57C, and the TSXPCI572/3.

Where does it physically install?

It installs directly into a dedicated slot on the front of the compatible processor unit, typically labeled as Slot 0.

Is the stored program permanent?

Programs stored in this Flash EPROM are retained until they are intentionally erased or overwritten. They are not lost during a power cycle, making them "non-volatile."

How do I transfer a program to this module?

You use the PL7 programming software. Once your program is developed and tested in the PLC's RAM, you can download it to the TSXMFPP128K module for permanent storage and backup.
