Schneider TSXP47425 | Compact Multi-Protocol Controller

The Schneider Electric TSXP47425 is a versatile and compact Modicon automation controller. It delivers robust processing power with extensive connectivity for mid-range industrial applications. This unit is engineered for reliable performance in demanding control environments.

Core Technical Specifications

• Brand & Model: Schneider Electric TSXP47425
• Product Line: Modicon Automation Controller
• Power Supply: 24V DC nominal (20-30V DC range), 1.2A current.
• Power Consumption: 15 Watts typical operating power.
• Processing Speed: 1 ms scan time per 1KB of program.
• Memory: 1 MB program memory, 128 KB data memory.

Connectivity & Communication

• Communication Ports: Supports Modbus, Ethernet, CANopen, and Profibus DP.
• I/O Capacity: Up to 256 digital I/O and 128 analog I/O points.
• Expansion: Features 4 expansion slots for additional I/O or communication modules.
• Real-Time Clock: Integrated, battery-backed clock for time-stamping and scheduling.

Physical & Environmental Data

• Dimensions (W x H x D): 130 mm x 160 mm x 115 mm.
• Weight: 2.63 lbs (1.19 kg).
• Mounting: Standard DIN rail mounting for easy panel installation.
• Protection Rating: IP20 for basic ingress protection.
• Operating Temperature: -10°C to +60°C (14°F to 140°F).
• Storage Temperature: -25°C to +70°C (-13°F to 158°F).

Key Features & Applications

• Ideal for machine control, process automation, and supervisory systems.
• Multiple protocol support ensures easy integration into diverse factory networks.
• Substantial I/O and expansion capacity allows for scalable system design.
• Battery-backed clock ensures data integrity and event logging during power loss.

Frequently Asked Questions (FAQ)

What is the main advantage of this controller?

Its key advantage is versatility, combining strong local I/O capacity with multiple built-in communication protocols in a compact, DIN-rail mountable package.

What kind of power supply does it need?

It requires a 24V DC power source. The input range is 20V to 30V DC, providing stability against typical line fluctuations.

How do I connect it to an Ethernet network?

The controller has a built-in Ethernet port. You can assign an IP address to connect it directly to a local area network for programming and data exchange.

Can I add more I/O points than the base unit supports?

Yes, you can expand the system using the 4 available expansion slots to add digital, analog, or specialty I/O modules as needed.

Is the real-time clock battery user-replaceable?

Typically, yes. The battery backs up the clock and RAM. Consult the user manual for the specific battery type and replacement procedure to maintain data integrity.
